AD111 Indicator Light

Home / Products / Electrical Accessories / Indicator Light / AD111 Indicator Light / 24v ac dc 22mm green led indicator light round indicator lights

  • 24v ac dc 22mm green led indicator light round indicator lights

  • 24v ac dc 22mm green led indicator light round indicator lights

24v ac dc 22mm green led indicator light round indicator lights

Product Type: AD111-22B/AC DC 24V G

Operating Temperature: -25℃~+55℃
Relative Air Humidity: ≤98%
Power Frequency Voltage:2.5KV, 1min
Insulation Resistance: ≥2MΩ
Continous Operating Life: ≥30000H
Brightness: ≥100cd/㎡
CTI: ≥100
Applying Frequency: AC50~60Hz
Protection Level: IP65
Certificate: CE、CCC、ROHS

Mounting hole size: 22mm


Product introduction

Product Description

24v ac dc 22mm green led indicator light round indicator lights

Place of OriginShanghai,China
Brand NameSK(Shangkai) yongxing switch
Product TypeAD111-22B/AC DC 24V G
Operating Temperature-25℃~+55℃
Relative Air Humidity≤98%
Power Frequency Voltage2.5KV, 1min
Insulation Resistance≥2MΩ
Continous Operating Life≥30000H
Brightness≥100cd/㎡
CTI≥100
Applying FrequencyAC50~60Hz
Protection LevelIP65
CertificateCE CCC ROHS
Mounting hole size22mm

Key Features

Multiple color scheme options: Different colors and designs are available to meet the individual needs of users or to identify different functions.

Waterproof design: With waterproof function, it can be used safely and reliably in the refrigerator environment.

Long life: has a long service life, stable and reliable, reduce replacement and maintenance costs.


FAQ

1.What is the indicator light?Indicator lights are a type of illuminating device that is commonly used to signify that equipment is either receiving power or that there is some form of malfunction. We have all seen the red light come on when you power on a device. That is an example of an indicator light.

2.Is this indicator light available in other colors?

Yes, our indicator lights may be available in a variety of color options to meet different user preferences and device appearance needs.


Product Size

24v ac dc 22mm green led indicator light round indicator lights

24v ac dc 22mm green led indicator light round indicator lights

Main customers

24v ac dc 22mm green led indicator light round indicator lights

24v ac dc 22mm green led indicator light round indicator lights
