KCD11 SPTT 10a 250v white on off on Rocker Switch

Name:KCD11 SPTT 10a 250v white on off on  Rocker Switch

Product Type:KCD11-13T-CA1H-B-W-139
Max.Rating Current:10A 250V AC
Contact Resistance:≤50mΩ
Insulation Resistance:≥100MΩ
Dielectric Strength:1,500VAC 1min
Electronic Life:10,000 cycles
Mechanical Life:50,000 cycles
Operating Temperature:T105
Certificate:CE、CQC

Product introduction

Key Feature

Multiple specifications: A variety of sizes and shapes are available to meet different user needs.

Widely used: suitable for household appliances, automobiles, ships, industrial equipment and other fields.

Easy installation: simple design, easy installation, suitable for various application scenarios.

FAQ

1.Do you support customized requirements?

Yes, we can provide customized services according to the specific needs of customers, including size, connection, gear and other aspects of customization.

Please contact our customer service team for more information.

2. How to choose the right gear or connection?

Users can choose the appropriate gear or connection mode according to the actual needs and circuit design requirements.

Usually in the product manual or specification table will provide detailed gear and connection information, users can refer to the selection.

3. Is this switch durable?

Yes, our products are made of high quality materials that are resistant to wear and high temperatures and designed to be rigorously tested

for a long service life and stable and reliable performance.


Product Size

KCD11 SPTT 10a 250v white on off on  Rocker Switch

KCD11 SPTT 10a 250v white on off on  Rocker Switch

KCD11 SPTT 10a 250v white on off on  Rocker Switch
