Home / Products / Electrical Accessories / Push Button Switch / LA133 Push Button Switch / 22mm momentary push button switch led light snap action 10a 660v mushroom red light switch push button
Model Number:LA133-A1.TD-K10 DC 12 R
Rated Insulation Voltage: AC660V
Rated Thermal Current: 10A
Varity of colors and lamp voltages,customization available
Product introduction
Product Description
22mm momentary push button switch led light snap action 10a 660v mushroom red light switch push button
| Model Number | LA133-A1.TD-K10 DC 12 R |
| Anti Vibration: | 10~2000Hz . 1mm . 15g |
| Operating Temperature | -25℃~+55℃ |
| Rated Insulation Voltage | AC660V |
| Rated Thermal Current | 10A |
| Max.insulation Voltage | 2500V/min |
| Electronic Life | 250,000~600,000 cycles |
| Mechanical Life | 300,000~1,000,000 cycles |
| Certificate | CE CCC ROHS |
| Protection Degree | IP40 IP65 IP67 |
Key Features
Multiple color scheme options: Different colors and designs are available to meet the individual needs of users or to identify different functions.
Safety performance: Some models of switches are designed with safety performance in mind, such as water, dust, fire and other features.
Wide application: momentary-machine-push-button-switch is widely used in electronic equipment, automation systems, mechanical equipment and other fields to trigger, control or select different functions.
FAQ
1.Are there any additional fittings or installation requirements?
Some models of momentary-illuminated-push-button-switch may require specific mounting accessories or fixtures, such as mounting bases or protective covers. Please review the product documentation or contact the supplier for details on the relevant accessories and installation requirements.
2.Does the push-button switch support multiple voltages?
Yes, momentary-illuminated-push-button-switch usually supports a variety of voltage supplies, such as 12V, 24V, 110V, etc. Check product specifications to ensure they meet your specific voltage requirements.
3.Will the indicator light stay on after the button is pressed?
The indicator light for momentary-illuminated-push-button-switch lights up when the button is pressed, but goes off when the button is released. The switch is instantaneous and only triggers the operation when the button is pressed.
Product Size
